Description
- EngineYanmar 3TNV88C Stage5
Supply diesel
Displacement 1642 cc, 3 Cylinders
Power 37 HP (27.5 kW)
Fuel tank capacity50 L Hydraulic oil tank25 L- Tractionhydraulic, 4 wheel drive (permanent even with narrow turning radius) Gearboxhydrostatic transmission with hydraulic motors on the 4 wheels ClutchHydraulic with electric control activated through PTO with blade brake
- Cutting heightAdjustable at 25 – 35 – 50 – 60 – 75 – 85 – 95 – 110 mm
- Grass collector capacity1200 L Grass catcher charging systemCharging turbine, 400 mm diameter, equipped with a hydraulic engine as well as a safety valve in order to avoid accidental damages. Independent activation from the cutting deck. Grass catcher equipped with motorised baffle inside the for even filling. Grass collector discharging systemHydraulic grass catcher emptying with automatic opening Maximal discharging height230 cm Rear projection30 cm
- Differential lockingSelf-engaging and manual by pushing the button
- Front tyresTurf 24×12.00-12 Rear tyresTurf 20×10.00-10 Steering systemHydro-steer SpeedContinuously variable from 0 to 20 km/h Inner turning radius62 cm SeatComfortable seat equipped with springs with arm-rests and adjustable
- Mowing capacity per hour (indicative)15500 m^2/h Standard features
- Automatic disengagement of blades and turbine when the grass catcher is full. Hydraulic cutting deck lifting and emptying. Lights and indicator kit
- Length261 cm without cutting deck – 347 cm with cutting deck
- Width138 cm without cutting deck – 162 cm with cutting deck
- Height183 cm with the roll bar let down – 243 cm with roll bar or cabin Distance between axles126 cm Clear span from the ground16 cm
- Weight1270 kg without cutting deck – 1490 kg with cutting deck
Fuel tank capacity50 L Hydraulic oil tank25 L
Tractionhydraulic, 4 wheel drive (permanent even with narrow turning radius) Gearboxhydrostatic transmission with hydraulic motors on the 4 wheels ClutchHydraulic with electric control activated through PTO with blade brake
Cutting heightAdjustable at 25 – 35 – 50 – 60 – 75 – 85 – 95 – 110 mm
Grass collector capacity1200 L Grass catcher charging systemCharging turbine, 400 mm diameter, equipped with a hydraulic engine as well as a safety valve in order to avoid accidental damages. Independent activation from the cutting deck. Grass catcher equipped with motorised baffle inside the for even filling. Grass collector discharging systemHydraulic grass catcher emptying with automatic opening Maximal discharging height230 cm Rear projection30 cm
Differential lockingSelf-engaging and manual by pushing the button
Front tyresTurf 24×12.00-12 Rear tyresTurf 20×10.00-10 Steering systemHydro-steer SpeedContinuously variable from 0 to 20 km/h Inner turning radius62 cm SeatComfortable seat equipped with springs with arm-rests and adjustable
Weight1270 kg without cutting deck – 1490 kg with cutting deck
